David SLS-2 Structured Light Color High Speed and Resolution High-Precision Mobile 3D Scanner
David SLS-2 Structured Color 3D Scanner David SLS-2 Structured Light Scanner Color 3D Scanning System DAVID High Speed and Resolution 3D Scanner with Laser Scanner and SLS2 Structured Light The scanner is mobile, so it can easily scan any surface and is approximately 0% of the object size. Accuracy to 1. Scan all edges of the object separately. Very little used, in best condition like new, except for the calibration unit connectors being removed and some of the paintwork worn (see photo). Everything is available except the original box.
The David SLS-2 Structured Light Scanner provides high-precision and high-speed 3D scanning at an affordable price.
The scanner employs innovative Structured Light technology, which allows precise 3D scanning in a matter of seconds. The scanner is mobile and can be easily placed in front of the surface to be scanned. A single click in the well-proven David software starts the scan. A few seconds later the digitized 3D model appears on your screen!
Scans of all of the sides of the object can be combined to create a closed 360° model. The modular hardware setup allows a flexible adaptation to your object - any size from a coin to a couch is possible!
The resulting scans can be exported in commonly used 3D file formats like OBJ, STL and PLY and processed in other applications, e.g. for rapid prototyping, inspection, product presentations, archeology and cultural heritage, works of art, computer animations, video games and so on. The limits are set only by your imagination!
Contents:
Industrial camera with high quality lens
Video projector with special lens for large focal range, including remote control
USB drive with David Pro Edition 3 software
Sliding rail (aluminium)
Camera slider
High quality tripod
Calibration panels printed on both sides for multiple scan volumes
Printed instructions
All required connecting cables
Adaptors for power supply to suit over 150 countries
Cable strapsThis advanced model enhances the well proven structured-light-technology with a way better handling. Never before it has been easier to adjust a 3D-scan-system on scanobjects taking different terms and various scanobject sizes into account.
The scanner is mobile and can be positioned easily in front of the surface to be scanned.
A single click in the well proven DAVID software starts the scanning process and a few seconds later the digitised 3D model appears on the screen – even the colours of the object can be optionally captured and reproduced in the resulting scan!
You are able to scan all of the sides of the object in succession and subsequently render an enclosed 360° model.
The 3D model can be exported to standard 3D file formats (such as OBJ, STL and PLY) and processed in other applications.
Specification
Package contents
David USB CMOS
David SLS-2 Structured Lightweight 3D Scanning System Projector
Remote control
Projector Slider Support Calibration unit
Tripod
Case
HDMI cable
USB cable
RS232 cable
David 3D Universal World Adapter
USB disk
Hex key
Allen key
Manuals
Velcro strapSpecs
Scan size: 60-500 mm
Resolution/Precision: Up to 0,05% of scan size (up to 0,05 mm)
Scanning time: One single scan within 2 seconds (or up to ~10 seconds, depending on settings and computer speed)
Mesh density: Up to 2,300,000 vertices per scan
Export formats: OBJ, STL, PLY
Max. resolution 0.06 mm
Max. accuracy 0.06 mm
Acquisition speed 570,000 points/sHardware Requirements
Standard-PC (64 bit - Windows Vista, 7, 8, 10)
3D graphics adapter
Available VGA or HDMI port
Two available USB ports
Conditions: Item not used very much, everything in pristine conditions except, glass calibration unit plastic clippings has worn off, but can be glued back if needed (please see pictures). Comes with everything seen in the pictures.
